systemd-journal-remote Guide | Central Log Collection

When you have more than a handful of servers, logging into each host to run journalctl does not scale. systemd can forward journals to a collector over HTTPS while keeping
the familiar journal fields (unit name, priority, boot ID) intact.

This complements local troubleshooting in our journalctl guide and log retention with
journal vacuum scripts. For long-term metrics, still ship important events to
Prometheus and Grafana.

Upload vs Remote: Two Roles

systemd-journal-upload runs on each client and pushes logs. systemd-journal-remote runs on the collector and writes incoming streams under /var/log/journal/remote/. You need both packages on their respective hosts.

architecturejournal-remote.txt

  [app servers] --HTTPS--> [collector: systemd-journal-remote]
                                      |
                               journalctl on collector

Client and collector — Upload pushes, remote receives

Install Packages

Package names differ slightly by distribution; the services are systemd-journal-upload and systemd-journal-remote.

bashDebian / Ubuntu

sudo apt install -y systemd-journal-remote

bashenable receiver on collector

sudo systemctl enable --now systemd-journal-remote.socket

Configure the Collector Socket

The collector listens on a TCP port (often 19532). Put it on a management VLAN and firewall it; do not expose log ingestion to the public internet without TLS and auth.

ini/etc/systemd/journal-remote.conf (snippet)

[Remote]
Storage=auto
Compress=yes

bashfirewall (example)

sudo ufw allow from 10.0.0.0/24 to any port 19532 proto tcp

Point Clients at the Collector

On each sending host, configure systemd-journal-upload with the collector URL. Use HTTPS when you terminate TLS on the collector or behind a reverse proxy.

ini/etc/systemd/journal-upload.conf

[Upload]
URL=https://logs.internal.example:19532/upload
ServerKeyFile=/etc/ssl/private/journal-upload.key
ServerCertificateFile=/etc/ssl/certs/journal-upload.pem

bashenable on client

sudo systemctl enable --now systemd-journal-upload.service

TLS Between Client and Collector

Generate or import certificates for mutual TLS or server-auth TLS depending on your threat model. At minimum use a private CA and verify the collector hostname.

bashtest HTTPS endpoint

curl -vk https://logs.internal.example:19532/

TipFor lab setups you can start with HTTP on a private network only, then add TLS before production.

Search Forwarded Logs on the Collector

Remote journals appear as separate files. Use journalctl with --directory or the MACHINE_ID / hostname fields to filter.

bashlist remote hosts

journalctl --directory=/var/log/journal/remote --list-boots

basherrors from one unit

journalctl --directory=/var/log/journal/remote -u nginx.service -p err --since today

journalctl on collector — Filter by host and unit

Retention and Disk on the Collector

Centralising logs concentrates disk use. Set SystemMaxUse in journald.conf on the collector and monitor free space.

ini/etc/systemd/journald.conf

SystemMaxUse=20G
MaxRetentionSec=30day

bashvacuum now

sudo journalctl --vacuum-size=15G

Quick Reference

Clients: systemd-journal-upload; collector: systemd-journal-remote
Firewall ingestion port; prefer HTTPS
Query with journalctl --directory=/var/log/journal/remote
